Original Network S 57 35-L24 P4S-A1 Ethernet Switch 24*10/100/1000base-T Ethernet Ports and 4 Gigabit SFP Poe

private mold : NO

products status : Stock

ports : 24

transmission rate : 10/100/1000Mbps

function : LACP, POE, QoS, SNMP

communication mode : Full-Duplex & Half-Duplex

switch capacity : /

brand name : /

model number : S 57 35-L 24P4S- A1

place of origin : Shanghai, China

Size : Customized Size

Color : Customizable

Suitable for : Workstation, Laptop, Desktop

Price : CN¥2,478.32/pieces >=1 pieces

Contact Now

Product Description

Original Network S 57 35-L24 P4S-A1 Ethernet Switch 24*10/100/1000base-T Ethernet Ports and 4 Gigabit SFP Poe

Dimensions with packaging (H x W x D) [mm(in.)]	90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U]	1 U
Typical power consumption [W]	41.7 W
Typical heat dissipation [BTU/hour]	142.29 BTU/hour
Maximum power consumption [W]	Not providing the PoE function: 53.2 W
	100% PoE loads: 433.2 W (PoE: 380 W)
Maximum heat dissipation [BTU/hour]	Not providing the PoE function: 181.52
MTBF [year]	55.72 year
MTTR [hour]	2 hour
Availability	>0.99999
Noise at normal temperature (acoustic power) [dB(A)]	50 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]	38.2 dB(A)
Storage temperature [°C(°F)]	-40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity [RH]	5% to 95%, noncondensing
Long-term operating altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Power supply mode	AC built-in
Rated input voltage [V]	AC input: 100 V AC to 240 V AC, 50/60 Hz
		High-Voltage DC input: 240 V DC

Input voltage range [V]	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
		High-Voltage DC input: 190 V DC to 290 V DC

Memory	512 MB
Flash memory	512 MB
Console port	RJ45
Eth Management port	Not supported
USB	Not supported
RTC	Not supported
RPS input	Not supported
Service port surge protection [kV]	Common mode: ±7 kV
Power supply surge protection [kV]	±6 kV in differential mode, ±6 kV in common mode
Types of fans	Built-in
Heat dissipation mode	Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction	Air intake from left and front, air exhaustion from right
PoE	Supported
